thread |
nominal
size |
ferrule i.d. (mm) |
dimension a (mm) |
dimension b (mm) |
dimension c (mm) |
packing (pcs) |
npt 1/2 |
3/8〞 |
11.00 |
29.00 |
38.10 |
21.30 |
100 |
npt 1/2 |
1/2〞 |
14.50 |
34.60 |
39.70 |
21.30 |
100 |
npt 3/4 |
3/4〞 |
19.50 |
42.00 |
41.30 |
26.70 |
50 |
npt 1 |
1〞 |
25.00 |
47.40 |
52.30 |
33.40 |
50 |
npt 1-1/4 |
1-1/4〞 |
33.50 |
58.00 |
60.50 |
42.20 |
25 |
npt 1-1/2 |
1-1/2〞 |
38.00 |
65.00 |
68.30 |
48.30 |
20 |
npt 2 |
2〞 |
49.50 |
78.00 |
80.50 |
60.30 |
10 |
npt 2-1/2 |
2-1/2〞 |
61.00 |
99.20 |
100.00 |
73.00 |
1 |
npt 3 |
3〞 |
76.00 |
118.30 |
105.00 |
88.90 |
1 |
npt 4 |
4〞 |
99.00 |
145.30 |
110.00 |
114.30 |
1 |
thread |
nominal
size |
ferrule i.d. (mm) |
dimension a (mm) |
dimension b (mm) |
dimension c (mm) |
packing (pcs) |
m16x1.5 |
3/8〞 |
11.00 |
29.00 |
38.10 |
16.00 |
50 |
m20x1.5 |
3/8〞 |
11.00 |
29.00 |
38.10 |
20.00 |
50 |
m20x1.5 |
1/2〞 |
14.50 |
34.60 |
39.70 |
20.00 |
50 |
m25x1.5 |
3/4〞 |
19.50 |
42.00 |
41.30 |
25.00 |
50 |
m32x1.5 |
1〞 |
25.00 |
47.40 |
52.30 |
32.00 |
50 |
m40x1.5 |
1-1/4〞 |
33.50 |
58.00 |
60.50 |
40.00 |
25 |
m50x1.5 |
1-1/2〞 |
38.00 |
65.00 |
68.30 |
50.00 |
20 |
m63x1.5 |
2〞 |
49.50 |
78.00 |
